YH135 - ROCK DRILLING

YH135 - ROCK DRILLING

53102943 - HYDRAULIC DRIFTER
51963684 - ASSEMBLY, BACKHEAD
51325041 - O-RING
51325058 - O-RING
51327716 - PIN, SPRING
50787753 - PLUG
51252971 - PLUG
51206100 - PLUG
51327724 - ADAPTER
51325488 - ADAPTER, OUTLET
51196350 - ADAPTER, HOSE
50748250 - SEAL
51960946 - PLUG
51327757 - SEAL
53103818 - ASSEMBLY, CYLINDER
53103768 - CYLINDER
51104248 - O-RING
51327773 - PLUG
51327781 - ELBOW
50787043 - O-RING
51669919 - LINER, CYLINDER
51669943 - ASSEMBLY, BACK LINER
51669950 - LINER, BACK
51325074 - SEAL
51325082 - SEAL
51325587 - GUIDE, VALVE
51669968 - VALVE
51325603 - PISTON
51680742 - ASSEMBLY, FRONT LINER
51325611 - LINER, FRONT
51325066 - SEAL
51325108 - RING, WIPER
51326668 - KEY
51104297 - O-RING
51155125 - ASSEMBLY, ACCUMULATOR
51206381 - BODY
51206399 - COVER
51206407 - DIAPHRAGM
51176741 - VALVE
51176758 - WASHER, SEAL
50748334 - CAP
51104198 - O-RING
51260032 - BOLT
51327815 - ASSEMBLY, HYDRAULIC MOTOR
51323319 - MOTOR, ROTATION
51327823 - ELBOW
51327831 - ELBOW, LONG
51325033 - O-RING
51327849 - GASKET
51325629 - BOLT, MOTOR
51327856 - ASSEMBLY, GEAR BOX
51325637 - BOX, GEAR
51327864 - BUSHING, DU
51176477 - PIN, SPRING
51206084 - O-RING
51327880 - ASSEMBLY, DRIVE GEAR
51325652 - GEAR, DRIVE
50748763 - BEARING, BALL
51327898 - ASSEMBLY, IDLE GEAR
51325645 - GEAR, IDLER
51327906 - BEARING, NEEDLE
51325546 - SHAFT, GEAR
50787019 - O-RING
51327914 - ASSEMBLY, GEAR BOX COVER
51325538 - COVER, GEAR BOX
51104206 - O-RING
50945385 - BOLT
51977565 - ASSEMBLY, CHUCK DRIVE
51325520 - DRIVER, CHUCK
51536605 - BUSHING SET
51534519 - CHUCK
51327930 - ASSEMBLY, CHUCK END
51325686 - CHUCK END
51104321 - O-RING
51327948 - BUSHING, DU
51325736 - BOLT
51325843 - NUT, NYLON
51327971 - ASSEMBLY, THROUGH BOLT
51324861 - BOLT, THROUGH
51103778 - O-RING
51325728 - NUT
51669927 - ASSEMBLY, FRONT GUIDE
51669935 - GUIDE, FRONT
51963692 - ASSEMBLY, FLUSHING CASE
51963700 - CASE, FLUSHING
51104230 - O-RING
51960979 - PLUG
51963932 - ELBOW
51103786 - O-RING
51963718 - ASSEMBLY, BUSHING
51963726 - BUSHING, FLUSHING HEAD
51961704 - U-PACKING
51961639 - ASSEMBLY, FLUSHING CAP
51961647 - CAP, FLUSHING
51961654 - LINER, CAP
51104222 - O-RING
50945161 - BOLT
51329092 - ASSEMBLY, BOLT

YH135 - ROTATION MOTOR

51323319 - ROTATION MOTOR
51541225 - SCREW
51541233 - RETAINER, FRONT
51541241 - KIT, SHAFT BEARING
51541258 - HOUSING, BEARING
51541266 - DRIVE
51541274 - GEROLER
51541282 - DRIVE, VALVE
51541290 - PLATE, VALVE
51541308 - VALVE
51541316 - PLATE, BALANCE
51541324 - SPRING
51541332 - HOUSING, VALVE
51541340 - ASSEMBLY, PLUG
51541357 - ASSEMBLY, CHECK PLUG
51541365 - SPRING
51541035 - BALL, STEEL
51541373 - BOLT
51541381 - BOLT
51325464 - KIT, MOTOR SEAL
51325116 - KIT, SHAFT SEAL
51325439 - KIT, MOTOR REAR SEAL

YH135 - REVERSE PERCUSSION KIT

53112728 - REVERSE PERCUSSION KIT
53113098 - ASSEMBLY, REVERSE CYLINDER
53113106 - CYLINDER, REVERSE
51547693 - SEAL, STEP
51325405 - RING, WEAR
51547701 - RING, WEAR
51176485 - PLUG
53113114 - PISTON, REVERSE
53126413 - ASSEMBLY, ACCUMULATOR
53113130 - WASHER, SEAL
51282655 - BOLT
51328037 - ASSEMBLY, BOLT
51325835 - BOLT
51325843 - NUT, NYLON
