HC112 - HYDRAULIC ROCK DRILL

HC112 - HYDRAULIC ROCK DRILL - Technical Specifications of Hydraulic Rock Drill – High Performance & Durability

Engineered for tough rock drilling applications, this hydraulic drifter offers superior performance, long service life, and seamless integration with your drilling system. Below are the detailed technical specifications optimized for demanding job site conditions.

Dimensions and Weight

• Weight: 248 kg (546 lb)

• Length without shank adapter: 1272 – 1316 mm

• Length with shank adapter: 1422 – 1466 mm

• Overall width: 332 mm (13 in)

• Height: 200.5 mm (7.9 in)

Rotation Specifications

• Maximum rotation speed:

  • 160cc: 169 rpm

  • 200cc: 135 rpm

• Hydraulic oil flow:

  • 160cc & 200cc: 75 l/min

• Maximum pressure: 210 bar

• Maximum torque:

  • 160cc: 1340 Nm

  • 200cc: 1680 Nm

Percussion Specifications

• Maximum output power: 26 – 30 kW (35 – 40 hp)

• Input power range: 37 – 50 kW (50 – 67 hp)

• Percussion flow rate: 172 l/min

• Percussion pressure: 190 bar (2755 psi)

• Maximum impact frequency: 46.67 Hz (2800 bpm)

Flushing and Lubrication

• Water flushing flow rate: 90 – 130 l/min

• Front-end lubricating air consumption: 300 l/min

Overhaul & Maintenance Kits

• Seal Kit

• 400 Impact Hours Kit

• 800 Impact Hours Kit

• 1600 Impact Hours Kit

• 3200 Impact Hours Kit

Compatible Shank Adapters

• D45 T38 M – 86638095

• D45 T45 M – 86638103

• D51 T45 M – 86621570

• D51 T51 M (RPH) – 86621596

• HC112 GT60

• D60 T51 M – 86742186

• D60 GT60 M – 86729936

Why Choose This Hydraulic Rock Drill?

This hydraulic rock drill is ideal for mining, tunneling, and quarrying operations requiring reliable impact energy and long-lasting performance. With its high torque, durable shank adapters, and optimized percussion system, it meets the toughest industry demands.

It is a manufacturer of affordable and best quality alternative spare parts for rock drilling machines, Aboveground and Underground Drilling and Tunneling Equipment in the mining and construction sectors.

BRK Rock Drill is a leading manufacturer of high-performance rock drilling machines and drilling equipment for the mining and construction industries. Known for its durable, efficient, and innovative solutions, BRK Rock Drill delivers reliable equipment designed to withstand the toughest working conditions in the global market.
We ship quickly from stock to any where in the world via UPS - DHL - FEDEX. Contact us now get the best price and best service All products are alternative production
